1H-2H Pencil Hardness Decorative Powder Coating RAL 1018 Zinc Yellow Color

Product Categories
Jinhu Color Powder Coating Co.Ltd
Contact Now

1H-2H Pencil Hardness Decorative Powder Coating RAL 1018 Zinc Yellow Color

  • 1
  • 2

Brand Name : TOPO

Model Number : D-RAL1018

Certification : CE, BV, ROHS

Place of Origin : Ukraine

MOQ : Negotiable

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 400 T/Month

Delivery Time : 7 days

Packaging Details : Two-ply PVC bag inside with carton box, net weight 20/25kg

Color : zinc yellow

RAL : 1018

drop hammer : 50kg.cm

Salt Spray Test : 500h

Curing conditions : 180°C/20min

Pencil hardness : 1H-2H

Contact Now

RAL1018 zinc yellow powder decorative coating absorb Turnkey Powder Coating Systems

TOPO System provides turn-key decoration equipment to OEMs, extruders, and powder coating facilities throughout the world. More than 100 companies throughout the world use TOPO's patented technology to create high-resolution wood grain, granite, marble, brushed, custom logos, and other decorative finishes on powder coated layers.

Our decorative finishes are used by many of the largest manufacturers in the world to decorate metals, MDF, etc.

Decoral can also custom build equipment to suit the specific needs of our clients.

SPECIFICATION

Coating film technical data
Curing conditions
180°C/20min, 190°C/15min, 200°C/10min
Impact resistance(drop hammer)
50kg.cm pass
Pencil hardness
H-2H
60°gauge head Gloss

High gloss type≥85% Semi gloss type:51-84%
Low gloss type:50-15% Matt type:<14%
Adhesion(cross cut test)
1mm 6x6 0 grade
Bending test(tapering spindle)
3mm pass
Salt Spray Testing
>500 hours
Humidity resistance
>1,000 hours

Application recommendation
Application Voltage
60-80KV
Film Thickness
60-80 Micron
Average coverage
8-12 square meters/kg, thickness 60μm(100% of the powder coating utilization rate)
